Self Locking Switch Factory 5.8* 5.8 6 Pin electrical self locking switch

Short Description:

Product name: Push Button Switch/ self locking switch

Operation Type: Momentary type /Latching type

Rating: DC 30V 0.1A

voltage: 12V or 3V, 5V, 24V, 110V, 220V

Contact Configuration: 1NO1NC


Product Detail

Product Tags

Product Name Push button switch
Model KFC-01-58T-1PZ
Operation Type momentary
Switch Combination 1NO1NC
Head Type Flat head
Terminal type Terminal
Enclosure Material Brass nickel
Delivery Days 3-7 days after payment received
Contact Resistance 50 mΩ max
Insulation Resistance 1000MΩ Min
Operating Temperature -20°C ~+55°C

PC端图片1

Introducing our innovative self-latching switch, a cutting-edge solution for power control and safety. This advanced key switch provides non-latching power on/off functionality, making it ideal for a variety of applications. With its SMD SMT availability and self-locking and unlocking capabilities, this switch provides unparalleled convenience and reliability. Whether you need to control access to sensitive equipment or just want a convenient way to power your equipment on and off, our latching switches are the perfect solution.



This self-latching switch is designed to meet the needs of modern technology, providing a compact and versatile solution for power control. Its SMD SMT availability ensures easy integration into a variety of electronic devices, making it suitable for consumer and industrial applications. With its non-latching power on/off function, this switch provides a simple and effective way to control the flow of electricity, bringing peace of mind and convenience to the user.



One of the key features of our self-locking switches is their self-locking and unlocking capabilities, which provide additional security and control. This feature allows the user to lock the switch in the desired position, preventing unauthorized access or unexpected power interruptions. The ability to unlock the switch when required ensures flexibility and ease of use, making it a versatile solution for a variety of applications.



Self-latching switches are ideal for applications where safety and control are critical. From industrial equipment to consumer electronics, this switch provides reliable and convenient power management. Its non-locking power on/off feature makes it easy to operate, while its self-locking and unlocking capabilities provide an extra layer of security, making it suitable for use in sensitive environments.
